Pride Series pumps are manufactured with a mechanical air valve and piston design which is more forgiving to environments with contaminated air. The 3:1 version is a medium pressure pump for supplying higher volume than the 5:1 version but at lower operating pressures ideal for medium pumping distances and overall flow rates of 4-5 gpm.
| RATIO | 3:1 |
| OPERATING AIR PRESSURE RANGE | 10–150 psi |
| DELIVERY RATE | 8 gpm |
| AIR CONSUMPTION | 19.70 SCFM |
| MAX FLUID STALL PRESSURE | 490 psi |
| CYCLES PER GALLON | 34 |
| AIR INLET | 1/4” NPT(f) |
| FLUID INLET | 1” NPT(f), 1-1/2” NPT(m) |
| FLUID OUTLET | 3/4” NPT(f) |
| EFFECTIVE AIR PISTON DIAMETER | 2.5” |
| WETTER MATERIALS | steel, Buna-N™, stainless steel, nickel plated steel, nylon, ultrathane, & aluminum |
NOTE: Thermal expansion of the fluid in a distribution system can cause an increase in system pressure that can damage lubrication system components. Use pressure relief valve kit included with this pump.
(1) Ensure that all hose fittings and piping are rated for fluid outlet pressures.
Warning! Do not use any LYNX® series products with flammable fluids.
Verify fluid compatibility with MSDS sheets.
- Pump
- Bung Adapter
- Pressure Relief Valve
- Suction Pipe*
- Air Hose*
- Oil Hose*
*TMO packages only
