| AIR INLET | 3/8" NPT(f) |
| FLUID INLET | 1-1/2" NPT(f) |
| FLUID OUTLET | 1/2" NPT(f) |
| AIRMOTOR EFFECTIVE DIAMETER | 3" |
| CYCLES PER GALLON | 30 |
| FLUIDS | oil |
| MAX AIR CONSUMPTION | 25 SCFM |
| MAX AIR INLET PRESSURE | 180 psi |
| MAX CONTINUOUS CYCLE RATE | 70 CPM |
| MAX INTERMINTENT CYCLE RATE | 70 CPM |
| MAX WORKING PRESSURE | 900 psi |
| POWER TYPE | pneumatic |
| RATIO | 5:1 |
| SOUND POWER LEVEL | 85.6 dBA |
| SOUND PRESSURE LEVEL | 77.8 dBA |
| WETTED MATERIALS | steel, polyurethane, aluminum, Buna-N |
| COMPATIBLE MATERIALS | oil, ATF |
| DISPENSE TYPE | manual |
| DISPLAY TYPE | electronic |
| EXTENSION TYPE | rigid |
| FLUID INLET | 1/2" NPT(f) |
| FLOW RATE | 0.25-8 gpm |
| MAX OPERATING TEMPERATURE | 158°F |
| MAX RECORDED DISPENSE | 9999 |
| MAX WORKING PRESSURE | 1,500 psi |
| METER ACCURACY | +/- 0.5 |
| WETTED MATERIALS | aluminum, stainless steel, PBT/PC, zinc, nitrile, rubber, CS |
| UNIT OF MEASURE | quart, pint, gallon, liter |
| TRIGGER PROTECTION TYPE | guard |
| TRIGGER LOCK | non-locking |
| RECOMMENDED ENVIRONMENT | indoor |
| OUTLET THREAD TYPE | straight thread o-ring boss |
| NOZZLE TYPE | automatic quick-close |
| POWER SOURCE | 4 AA batteries |
| HOSE INSIDE DIAMETER | 1/2" |
| HOSE LENGTH | 50' |
| INLET SIZE | 1/2" NPSM |
| MAX TEMPERATURE | 190°F |
| MAX WORKING PRESSURE | 2,000 psi |
| MOUNT LOCATION | truck mount, bench mount |
| OUTLET | 1/2" NPT(m) |
| WETTED MATERIALS | zinc-plated steel, anodized aluminum, nitrile rubber |
| FLUIDS HANDLED | oil |
| TYPE | spring-rewind |
| RECOMMENDED ENVIRONMENT | indoor, limited outdoor |
| FRAME TYPE | single pedestal |
*Hose reel inlet kit GRA-218549 sold separately.
